The semiaquatic Northern Map Turtle is characterized by a short tail, a rigid upper and lower shell, an upper shell with a roughly jagged rear edge, a small yellow spot behind each eye, and dark-colored seams between the large scutes on the lower shell. The upper shell is dull olive-gray with yellowish lines and circles. The lower shell is gray and lacks a pattern, but the seams between each scute are darker than the lower shell color. The head, limbs, and tail are olive or brownish with yellow stripes. Males have longer tails than females. Females have broader heads and reach a much larger size than males.
Adults are normally 90-253 mm (3½-10 inches) in carapace length. The largest specimen from Kansas is a female (KU Color Slide 8872) from Osage County with a carapace length of 226 mm (87⁄8 inches) collected by Lenn Shipman and Warren Voorhees on 3 July 1990. The maximum carapace length throughout the range is 269.9 mm (105⁄8 inches) (Powell et al., 2016).
The Northern Map turtle is known from the Marais des Cygnes, Verdigris, and Caney drainage systems in eastern Kansas. This species inhabits slow-moving stretches and backwaters of rivers, streams, and lakes.
Additional records (both from 1911) exist for Montgomery (KU 3267) and Wilson (KU 3285) but are too imprecise to plot. These records are mapped in Collins (1993).
David Edds and his students at Emporia State University studied this species in Kansas (Edds et al., 1990; Edds, 1991), and much of the information known about this turtle in Kansas is based on their work.
This species prefers slow-moving or still bodies of water ranging in size from small stream to rivers, including river oxbows and lakes. Clarke (1953) found a specimen •in a small stream in Osage County. Edds (1991) reported ten of these turtles in streams 15 to 60 feet wide with shorelines shaded by trees; little vegetation and few basking sites were evident.
The Northern Map Turtle is probably active from April to October; it has definitely been documented in Kansas from 24 June to 6 October. It becomes less active during the winter but may not actually burrow in the mud as do some of the other semiaquatic turtles.
Northern Map Turtles spend most of the day basking and sleeping in the sun on logs or other suitable perches, evidently foraging for food at twilight and after dark. They are gregarious, congregating in large numbers at optimal sites, and are extremely wary when approached.
This shy turtle may mate twice each season but generally initiates breeding in the spring. Nothing is known of courtship in this species in Kansas. Females dig nests from May to July along the water's edge in soft soil or sand but normally not on beaches. Each female lays from 10- 16 elongate dull white eggs. If they are laid in early spring, hatching will occur in early fall. Eggs laid during the summer or fall may not hatch until the following spring.
The Northern Map Turtle feeds on crayfishes and freshwater mussels but apparently does not prey on fishes (Collins, 1993).
First reported from Kansas by Cragin (1880) from specimens observed around Ottawa, Franklin County. Though Burt (1933) mentioned "A small turtle (K.S.C. 374), which apparently belongs to this
species, was secured near Manhattan, Riley County, by J. B.
Norton, in July, 1897.", this specimen is more likely Graptemys ouachitensis/pseudogeographica. The oldest extant specimens known from Kansas were all collected in 1911 are from Montgomery County (KU 3267; Verdigris River; July), Franklin County (KU 3225, 3265; Marais des Cygnes River, Ottawa, Franklin County), and Wilson County (KU 3285; no other locality data).
Formerly considered extirpated in Kansas (Capron, 1985). Edds (1990, 1991) discovered six new localities in the Marais des Cygnes drainage. The Northern Map Turtle is shy and retiring, usually avoiding the main stem of Kansas' larger rivers, in favor of smaller tributaries with denser canopies.
Recent observations from Chautauqua and Wilson counties help corroborate specimens from the Verdigris River drainage mapped by Collins (1993). Voucher specimens are desirable from this area, should they ever become available.
There is little evidence to suggest that populations have changed much over the past 50 years. However, because it is known from so few localities, those sites should be monitored regularly and new sites should be surveyed.
Two recent observations in Johnson County along Wolf Creek and the Blue River (~2 miles apart) warrant further investigation.
Listed as a Kansas Threatened species in 1993. No recovery plan exists for this species. Edds (1991) recommended this species be designated endangered in Kansas because of water pollution, habitat destruction, and a decline in the state's freshwater mussel populations.
As defined by Kansas Administrative Regulations, critical habitats include those areas documented as currently supporting self-sustaining population(s) of any threatened or endangered species of wildlife as well as those areas determined by the Kansas Department of Wildlife, Parks, and Tourism to be essential for the conservation of any threatened or endangered species of wildlife
Currently, the following areas are designated critical for Northern Map Turtles:
(1) The main stem of the Marmaton River from Moran, Allen County (Sec. 36-T24S-R20E) to the Kansas/Missouri border in Bourbon County (Sec. 24-T25S-R25E).
(2) The main stem of Cedar Creek in Anderson County from its point of entry into Sec. 1-T22S-R18E to its confluence with Pottawatomie Creek (Sec. 1-T20S-R19E).
(3) The main stem of the South Fork of Pottawatomie Creek in Anderson County from its point of entry into Sec. 27-T21S-R20E to the confluence with Pottawatomie Creek (Sec. 24- T19S-R20E).
(4) The main stem of the West Fork of Tauy Creek in Franklin County from the Douglas/Franklin County border (Sec. 23-T15S-R19E) to the confluence with Ottawa Creek (Sec. 28-T16S-R20E).
(5) The main stem of Ottawa Creek in Franklin County from the confluence of the West Fork of Tauy Creek (Sec. 23-T15S-R19E) to the confluence with the Marais des Cygnes River (Sec. 11-T17S-R20E).
(6) The main stem of Long Creek in Osage County from the Osage/Coffey County border (Sec. 36-T18S-R15E) to the confluence of the Marais des Cygnes River (Sec. 2-T18S-R16E).
(7) The main stem of Frog Creek in Osage County from the Osage/Coffey County border (Sec. 34-T18S-R15E) to the confluence with Long Creek (Sec. 30-T18S-R16E).
(8) The main stem of the Little Osage River in Bourbon County from the Bourbon/Allen County border (Sec. 36-T23S-R21E) to the Kansas/Missouri border (Sec. 1-T24S-R25E).
(9) The main stem of Appanoose Creek in Franklin County from the Osage/Franklin border (Sec. 23-T15S-R17E) to the confluence with the Marais des Cygnes River (Sec. 32-T16S-R19E).
Based on a captive specimen, Snider and Bowler (1992) reported a maximum longevity for this turtle of eighteen years and 21 days.
References
Agassiz, Louis. 1857. Contributions to the Natural History of the United States of America. Volume 1. Little, Brown & Company, Boston, Massachusets. 452 pp.
Cragin, Francis W. 1880. A preliminary catalogue of Kansas reptiles and batrachians. Transactions of the Kansas Academy of Science 7:112-123.
Hurter, Julius. 1911. Herpetology of Missouri. Transactions of the Academy of Science of St. Louis 20(5):59-274.
Householder, Victor H. 1916. The Lizards and Turtles of Kansas with Notes on Their Distribution and Habitat. Thesis. University of Kansas, Lawrence. 100 pp.
Ortenburger, Arthur I. 1928. The whip snakes and racers: Genera Masticophis and Coluber. Memiors of the University of Michigan Museum (1):1-247.
White, Theodore E. 1929. The osteology of the recent turtles of central North America. Thesis. University of Kansas, Lawrence, Kansas. 309 pp.
Burt, Charles E. 1933. Some distributional and ecological records of Kansas reptiles. Transactions of the Academy of Science of St. Louis 26:186-208.
Brumwell, Malcolm J. 1936. Distributional records of the reptilia and amphibians of Kansas. Privately printed. 22 pp.
Hall, Henry H. and Hobart M. Smith. 1947. Selected records of reptiles and amphibians from southeastern Kansas. Transactions of the Kansas Academy of Science 49(4):447-454.
Smith, Hobart M. 1950. Handbook of Amphibians and Reptiles of Kansas. University of Kansas, Museum of Natural History, Miscellaneous Publication (2):336.
Schmidt, Karl P. 1953. A Check List of North American Amphibians and Reptiles. 6th Edition. University of Chicago Press, Chicago, Illinois. 280 pp.
Smith, Hobart M. 1956. Handbook of Amphibians and Reptiles of Kansas. Second edition. University of Kansas Museum of Natural History Miscellaneous Publication (9):1-356.
Clarke, Robert F. 1956. Turtles in Kansas. Kansas School Naturalist 2(4):1-15.
Clarke, Robert F. 1956. Identification of Kansas turtles. Kansas School Naturalist 2(4):1-3.
Choate, Jerry R. 1967. Wildlife in the Wakarusa Watershed of Northeastern Kansas. Kansas Biological Survey, Lawrence. 46 pp.
Gier, Herschel T. 1967. Vertebrates of the Flint Hills. Transactions of the Kansas Academy of Science 70(1):51-59.
Holman, J. Alan. 1972. Herpetofauna of the Kanopolis local fauna (Pleistocene: Yarmouth) of Kansas. Michigan Academician 5:87-98.
Collins, Joseph T. 1974. Amphibians and Reptiles in Kansas. University of Kansas Museum of Natural History Public Education Series (1):283 pp.
Karns, Daryl, Ray E. Ashton, Jr., and Thomas Swearingen. 1974. Illustrated Guide to Amphibians and Reptiles in Kansas: An Identification Manual. University of Kansas Publications Museum of Natural History Public Education Series(2):viii + 18.
Rundquist, Eric M. 1976. Field checklist (of) amphibians and reptiles of Kansas. Kansas Herpetological Society, Lawrence.
Perry, Jan. 1976. Field trip to southeast Kansas planned. Kansas Herpetological Society Newsletter (12):1.
Hibbard, Claude W., Richard J. Zakrzewski, Ralph E. Eshelman, Gordon Edmund, Clayton D. Griggs, and Caroline Griggs. 1978. Mammals from the Kanopolis Local Fauna, Pleistocene (Yarmouth) of Ellsworth County, Kansas. Contributions from the Museum of Paleontology, The University of Michigan 25(2):11-44.
Martin, Larry D. 1979. Survey of fossil vertebrates from east-central Kansas: Kansas River bank stabilization study. U.S. Army Corps of Engineers, Kansas City District. 55 pp.
Preston, Robert E. 1979. Late Pleistocene cold-blooded vertebrate faunas from the mid-continental United States, I. Reptilia: Testudines, Crocodilia. University of Michigan Museum of Palenontology, Papers on Paleontology. (19):1-53..
Collins, Joseph T. 1982. Amphibians and Reptiles in Kansas. 2nd edition. University of Kansas Museum of Natural History Public Education Series (8).
Brown, Kenneth L. 1984. Pomona: A plains village variant in eastern Kansas and western Missouri. Dissertation. University of Kansas, Lawrence, Kansas. 519 pp.
Secor, Stephen M. and Charles C. Carpenter. 1984. Distribution maps of Oklahoma reptiles. Oklahoma Herpetological Society Special Publication (3):1-57.
Busby, William H. 1988. The Kansas Natural Heritage Program: Taking stock of Kansas' natural heritage. Kansas Herpetological Society Newsletter (71):9-12.
Collins, Joseph T. 1990. Maximum size records for Kansas amphibians and reptiles. Kansas Herpetological Society Newsletter (81):13-17.
Edds, David, Warren Voorhees, Judy Schnell, and Lenn Shipman. 1990. Common Map Turtle rediscovered in Kansas. Kansas Herpetological Society Newsletter (82):12.
McCoy, Clarence J., Jr., and Richard C. Vogt. 1990. Graptemys geographica. Catalogue of American Amphibians and Reptiles (484):1-7.
Conant, Roger and Joseph T. Collins. 1991. Peterson Field Guide to Reptiles and Amphibians of Eastern and Central North America. 3rd ed. Houghton Mifflin Company, Boston, Massachusetts.
Edds, David R. 1991. Conservation status of the Common Map Turtle in Kansas. Agency Contract # 259. :45.
Collins, Joseph T. 1991. New records of amphibians and reptiles in Kansas for 1990. Kansas Herpetological Society Newsletter (83):7-13.
Voorhees, William, J. Schnell, and David Edds. 1991. Bait preferences of semiaquatic turtles in southeast Kansas. Kansas Herpetological Society Newsletter (85):14-13.
Rundquist, Eric M. 1992. Kansas endangered, threatened, and SINC species. Kansas Herpetological Society Newsletter (91).
Taggart, Travis W. 1992. KHS field trips. Kansas Herpetological Society Newsletter (91):3.
Freeman, Craig C. and William H. Busby. 1993. A survey for endangered and threatened species on the Sunflower Army Ammunition Plant, Johnson County, Kansas. Report No. 54. Kansas Biological Survey, Lawrence. 115 pp.
Collins, Joseph T. and Suzanne L. Collins. 1993. Amphibians and Reptiles in Kansas. Third Edition. University Press of Kansas, Lawrence, Lawrence. 397 pp.
Kirkpatrick, D. 1993. Map turtles of the United States. Reptile & Amphibian Magazine (November-December):6-17.
McCoy, Clarence J., Jr., and Richard C. Vogt. 1994. Graptemys. Catalogue of American Amphibians and Reptiles (584):1-3.
Fuselier, Linda, and David Edds. 1994. Habitat partitioning among three sympatric species of map turtles, genus Graptemys. Journal of Herpetology 28(2):154-158.
Dloogatch, Michael A. (Editor). 1994. Herpetology 1994. Bulletin of the Chicago Herpetological Society 29(12):282-283.
Holman, J. Alan. 1995. Pleistocene Amphibians and Reptiles. Oxford University Press, New York. 243 pp.
Rundquist, Eric M. 1996. Results of the eighth annual KHS herp counts Held 1 April-31 May 1996. Kansas Herpetological Society Newsletter (104):6-17.
Rakestraw, J. 1996. Spring herp counts: A Kansas tradition. Reptile & Amphibian Magazine (March-April):75-80.
Conant, Roger and Joseph T. Collins. 1998. Peterson Field Guide to Reptiles and Amphibians of Eastern and Central North America. 3rd ed, expanded. Houghton Mifflin Company, Boston, Massachusetts.
Powell, Robert, Joseph T Collins, and Errol D Hooper Jr. 1998. A Key to Amphibians & Reptiles of the Continental United States and Canada. Univ Press of Kansas, Lawrence, Kansas. 131 pp.
Gamble, Jerre. 1998. Marais des Cygnes National Wildlife Refuge Comprehensive Conservation Plan. U.S. Fish and Wildlife Service, Hartford, Kansas. 91 pp.
Rundquist, Eric M. 1999. Kansas Herpetological Society herp counts: A 10 year summary and evaluation. Kansas Herpetological Society Newsletter (115):42962.
Kingsbury, Bruce and Joanna Gibson. 2002. Habitat Management Guidelines for Amphibians and Reptiles of the Midwest. Publication of Partners in Amphibian and Reptile Conservation, Address not given. 152 pp.
Browne, Constance L. and Stephen J. Hecnar. 2005. Capture success of Northern Map Turtles (Graptemys geographica) and other turtle species in basking vs. baited hoop traps. Herpetological Review 36(2):145-147.
Taggart, Travis W. 2006. Distribution and status of Kansas herpetofauna in need of information. State Wildlife Grant T7. Kansas Department of Wildlife and Parks, Pratt. vii + 106 pp.
Economics, Industrial, Incorporated. 2008. Cherokee County: Restoration Plan / Environmental Assessment. Prepared for: US Department of the Interior, US Fish and Wildlife Service. Industrial Economics, Incorporated, Cambridge, MA. 138 pp.
Taggart, Travis W. 2008. KHS 2008 spring field trip. Journal of Kansas Herpetology (25):2-3.
Collins, Joseph T., Suzanne L. Collins, and Travis W. Taggart. 2010. Amphibians, Reptiles, and Turtles of Kansas. Eagle Mountain Publishing., Provo, Utah. 400 pp.
Taggart, Travis W. 2011. Kansas Herpetological Society 2011 spring field trip to be held in Chautauqua County. Journal of Kansas Herpetology (37):5-7.
Rohweder, Megan R. 2012. Spatial conservation prioritization of Kansas for terrestrial vertebrates. Thesis. Fort Hays State University, Hays, Kansas. 151 pp.
Powell, Robert, Joseph T Collins, and Errol D Hooper Jr. 2012. Key to the Herpetofauna of the Continental United States and Canada: Second Edition, Revised and Updated. Univ Press of Kansas, Lawrence, Kansas. 152 pp.
Taggart, Travis W. 2014. Recent scientific and standard English name changes effecting the Kansas herpetofauna. Collinsorum 3(2-4):9-10.
Lindeman, Peter V. 2014. Surveys of basking turtles in the rivers of northeastern Oklahoma, with emphasis on Graptemys geographica (Common Map Turtle). Proceedings of the Oklahoma Academy of Science 94:1-9.
Rohweder, Megan R. 2015. Kansas Wildlife Action Plan. Ecological Services Section, Kansas Department of Wildlife, Parks and Tourism in cooperation with the Kansas Biological Survey. 176 pp.
Lindeman, Peter V. 2016. The Map Turtle and Sawback Atlas: Ecology, Evolution, Distribution, and Conservation. University of Oklahoma Press, Norman. 488 pp.
Powell, Robert, Roger Conant, and Joseph T. Collins. 2016. Peterson Field Guide to Reptiles and Amphibians of Eastern and Central North America. Houghton Mifflin Harcourt, Boston. 494 pp.
Taggart, Travis W. and J. Daren Riedle. 2017. A Pocket Guide to
Kansas Amphibians,
Turtles and Lizards. Great Plains Nature Center, Wichita, Kansas. 69 pp.
Crother, Brian I. (editor). 2017. Scientific and Standard English Names of Amphibians and Reptiles of North America North of Mexico, with Comments Regarding Confidence in Our Understanding. Eighth edition. Herpetological Circulars (43):1-102.
Praschag, Peter, Flora Ihlow, Morris Flecks, Melita Vamberger, and Uwe Fritz. 2017. Diversity of North American map and sawback turtles (Testudines: Emydidae: Graptemys). Zoologica Scripta 46:675-682.
Petersen, Christopher E., Robert E. Lovich, and Sarah Stallings. 2018. Amphibians and reptiles of United States Department of Defense installations. Herpetological Conservation and Biology 13(3):652–661.
Powell, Robert, Joseph T Collins, and Errol D Hooper Jr. 2019. Key to the Herpetofauna of the Continental United States and Canada. Third Edition. Univ Press of Kansas, Lawrence, Kansas. 192 pp.
Mahr, Michael S. 2020. Distributions and statuses of map turtles (Graptemys sp.) in Kansas. Thesis. Emporia State University, Emporia, Kansas.. 131 pp.
Daniel, Richard E. and Brian S. Edmond. 2020. Atlas of Missouri Amphibians and Reptiles for 2019. Privately printed, Columbia, Missouri. 86 pp.
Riedle, J. Daren. 2020. Revisiting Kansas Herpetological Society field trip and Herp Count data:
Distributional patterns and trend data of Kansas amphibians and reptiles. Collinsorum 9(1):7-16.
Rader, Jennifer. 2020. Southeast Kansas Nature Center. Kansas Wildlife and Parks Magazine July-August:38-41.
Rhodin, Anders G. J., John B. Iverson, Roger Bour, Uwe Fritz, Arthur Georges, H. Bradley Shaffer, and Peter Paul van Dijk. 2021. Turtles and tortoises of the world during the rise and global spread of humanity: First checklist and review of extinct pleistocene and holocene chelonians. Chelonian Research Monographs (8):1-472.
Autz, Justin J., Alexis F. L. A. Powell, Jennifer L. Buchanan, Michael S. Hahr, Lynnette M. Sievert, David R. Edds, and J. Daren Riedle. 2021. Geographic distribution: Necturus maculosus; Kansas. Herpetological Review 52(1):74-75.
Powell, Alexis F. L. A., Michael S. Mahr, Jennifer L. Buchanan, and Justin Autz. 2021. New records of the Northern Map Turtle
(Graptemys geographica) redefine its known
distribution and abundance in Kansas, USA. Herpetological Review 52(4):737–742.
Thomson, Robert C., Phillip Q. Spinks, and H. Bradley Shaffer. 2021. A global phylogeny of turtles reveals a burst of climate-associated diversification on continental margins. Proceedings of the National Academy of Sciences of the United States of America 118(7):1-10.
Powell, Alexis F. L. A. and Greg Sievert. 2022. New distributional records of turtles in eastern Kansas and western Missouri, USA. Herpetological Review 53(2):265–271.
Ward, Jessica. 2025. KDWP proposes moving three species from threatened to species in need of conservation status. Kansas Wildlife & Parks Magazine 81(6):8-9.
Hofmeier, Jordan. 2025. For the future: Conserving Kansas' endangered wildlife. Kansas Wildlife & Parks Magazine 2025(November):17-23.
Ward, Jessica. 2025. Species profile: Northern Map Turtle. Kansas Wildlife & Parks Magazine 2025(November):44.
